These endpoints are used by POS systems to post transaction data into the ClearLine system.
Based on this data, ClearLine identifies the customer and executes business rules to process it and apply Loyalty Program logic (calculate points, stamps, change user’s tier, grant rewards, etc.).

ClearLine retrieves its configuration from POS system using Get POS Settings
POS system initializes a session with Start POS Interaction
ClearLine sends a webhook with customer details (loyalty card, email, phone, name) for customer check-in
POS system posts transaction data into ClearLine using the Transaction endpoint; ClearLine applies loyalty logic (points, stamps, tier changes, rewards)
POS system can fetch customer coupons using couponCode/search
POS system can validate a coupon against a transaction using Validate Coupon by Transaction

1. Transaction

1. Get POS Settings

Endpoint:
GET /v2/pos/{posSystemId}/settings/lookup Description:
Retrieves POS system settings.
If the integration works only with one POS provider (Cova, Clover, or Pax), the response will contain settings only for that provider. Path Parameters:

posSystemId (string, required) – POS system identifier.

Responses

200 (Success)

{
    "data": {
        "companySettings": {
            "isCheckInMenuEnabled": true,
            "isTransactionsEnabled": true,
            "isPosRulesEnabled": true,
            "isReceiptPromotionEnabled": true,
            "isCouponsEnabled": true,
            "isProductsImportEnabled": true
        },
        "notificationSettings": {
            "status": "Enabled",
            "channel": "PubNub",
            "configuration": {
                "publishKey": "pub-c-xxxxxxxxxxxxxxxxxxxxxxxxxx",
                "subscribeKey": "sub-c-xxxxxxxxxxxxxxxxxxxxxxxxxx",
                "terminalChannel": "pos_system_message-{terminalId}",
                "broadcastChannel": "pos_system_message-[all]"
            }
        }
    }

Response parameters

Field name	Description
data	Data Block
companySettings	Data Block
isCheckInMenuEnabled	Identifies if CheckIn menu is enabled
isTransactionsEnabled	Identifies if transaction synchronization enabled on this account
isPosRulesEnabled	Identifies if automatic POS Rules enabled on this account
isReceiptPromotionEnabled	Identifies if QR code generation enabled to print it on receipts on this account
isCouponsEnabled	Identifies if Coupons are enabled
isProductsImportEnabled	Identifies if automatic Product Catalog import enabled on this account
notificationSettings	Data Block
status	Status of notifications [Enabled, Disabled]
channel	Identifies the notification channel [None, Webhook, PubNub]
configuration	Data Block (PubSub sample)
publishKey	Publish key
subscribeKey	Subscribe key
terminalChannel	Terminal channel, used to send messages to a specific terminal
broadcastChannel	Broadcast channel, used to send messages to all terminals on the account

2. Start POS Interaction

Endpoint:
POST /Pos/{posSystemId}/startInteraction Description:
Initializes a POS session with ClearLine. Path Parameters:

posSystemId (string, required) – POS system identifier.

Example Request

{
  "terminalId": "string",
  "posLocationId": "string"
}

Example Response (200 Success)

{
  "data": {
    "terminalId": "string",
    "posLocationId": "string",
    "sessionId": "string",
    "posStatus": "Accepted"
  }
}

Schema:

StartInteractionRequestDto
- terminalId (string, required) – Terminal identifier
- posLocationId (string, required) – POS Location identifier

3. Submit Transaction

Endpoint:
POST /Pos/{posSystemId}/transaction Description:
Sends transaction data from POS to ClearLine.
Requires sessionId obtained from /startInteraction. Path Parameters:

posSystemId (string, required) – POS system identifier.

Example Request

{
  "sessionId": "string",
  "customer": {
    "id": "string",
    "firstName": "string",
    "lastName": "string",
    "birthDate": "2025-09-24T06:13:50.402Z",
    "contacts": [
      {
        "email": "string",
        "phone": "string"
      }
    ]
  },
  "salesPerson": {
    "id": "string",
    "firstName": "string",
    "lastName": "string"
  },
  "purchaseName": "string",
  "purchaseId": "string",
  "purchaseQuantity": 0,
  "purchasePrice": "string",
  "transactionId": "string",
  "transactionType": "Undefined",
  "transactionAmount": 0,
  "transactionDate": "2025-09-24T06:13:50.402Z",
  "terminalId": "string",
  "posLocationId": "string",
  "products": [
    {
      "productId": "string",
      "productName": "string",
      "manufacturer": "string",
      "productCategory": "string",
      "quantity": 0
    }
  ],
  "loyalty": {
    "cardNumber": "string"
  }
}

Example Response (200 Success)

{
  "data": {
    "id": "string",
    "qrCodeWidget": {
      "shortLinkUrl": "string",
      "qrCode": {
        "htmlLinkUrl": "string",
        "previewHtmlLinkUrl": "string"
      },
      "notificationMessageId": "string",
      "profile": {
        "id": "string",
        "firstName": "string",
        "lastName": "string",
        "customerEmail": "string",
        "customerPhone": "string",
        "salesPerson": "string",
        "purchaseName": "string",
        "purchaseId": "string",
        "purchaseCategory": "string",
        "purchasePrice": "string",
        "gender": "string"
      },
      "sessionId": "string"
    },
    "cfsTemplate": {
      "accountTemplateId": 0,
      "cfsCarouselUrl": "string"
    },
    "posStatus": "Accepted",
    "loyalty": {
      "status": "Applied",
      "awardDescription": "string",
      "qrCode": {
        "linkUrl": "string",
        "qrCodeLinkUrl": "string",
        "primaryText": "string",
        "secondaryText": "string"
      }
    }
  }
}

Schema Highlights:

NewPosTransactionRequestDto
- sessionId (string, required) – Session identifier
- customer (PosTransactionCustomerDto, optional) – Customer info
- salesPerson (PosTransactionSalesPersonDto, optional) – Sales person info
- purchaseName, purchaseId, purchaseQuantity, purchasePrice
- transactionId (string, required) – Transaction identifier
- transactionType (enum, optional)
- transactionAmount (number, optional)
- transactionDate (datetime, required)
- terminalId, posLocationId (string, required)
- products[] (PosTransactionProductDto, optional)
- loyalty (PosTransactionLoyaltyProgramDto, optional) – Loyalty card number
NewPosTransactionResponseDtoApiResponse
- id (string, optional) – Transaction Id
- qrCodeWidget (WidgetMessageResultDto) – QR code & notification details
- cfsTemplate (CfsTemplateMessageResultDto) – CFS campaign template data
- posStatus (enum: Accepted, Disabled, NotAvailable)
- loyalty (PosTransactionLoyaltyResponseDto) – Loyalty program reward details

After a transaction, the POS system receives the following data in the response, which can be printed on the customer’s receipt:

**Description **– Loyalty details such as the updated customer balance and the number of points earned
QR Code – An image URL linking to the Loyalty Program
**Primary & Secondary Text **– Brief information about the Loyalty Program or additional promotional details

2. Customer Check-In & Loyalty Card retrieval

1. Get a Webhook with the Customer Details

Once a customer is checked in via CFS or CMC, Clearline sends a webhook notification with the following customer details:

Loyalty Card Number
Loyalty User ID
Email
Phone
First Name
Last Name
SentAd

To display customer details at the POS, the system can use the User Card Details endpoint:

2. Get Loyalty Card details

Endpoint:

GET /v2/pos//loyaltyCard/lookup

Retrieve loyalty card details for a specific location. Path Parameters:

posSystemId (string, required) – POS system identifier.

Request

{
    "posLocationId": "{{PosLocationId}}"
}

Responses

Code 200 – success

{
  "data": {
    "loyaltyCard": {
      "id": "string",
      "name": "string",
      "title": "string",
      "description": "string",
      "frontImage": "string",
      "loyaltyCardType": 1,
      "location": {
        "id": "string",
        "name": "string"
      }
    }
  }
}

Schema

LoyaltyCard

id (string, nullable) – Loyalty card unique identifier
name (string, nullable) – Loyalty card name
title (string, nullable) – Loyalty card title
description (string, nullable) – Loyalty card description
frontImage (string, nullable) – Front image URL

Location

id (string, nullable) – Location unique identifier
name (string, nullable) – Location name

3. Coupon validation

1. Get customer coupons

Endpoint:
POST /pos/{posSystemId}/coupon/couponCode/search Description:
Returns customer coupons by search parameters Path Parameters:

posSystemId (string, required) – POS system identifier.

Example Request

{
  "code": "string",
  "email": "string",
  "phone": "string",
  "posLocationId": "string"
}

Schema

code (string, nullable) – Filter by coupon code
email (string, nullable) – Filter by customer email
phone (string, nullable) – Filter by customer phone number
posLocationId (string, nullable) – POS location identifier

Responses

200 (Success)

{
  "data": [
    {
      "rewardProvider": "TwoReward",
      "code": "string",
      "name": "string",
      "title": "string",
      "pictureUrl": "string",
      "availableUntil": "2025-09-25T07:52:57.104Z",
      "status": "Issued",
      "info": [
        {
          "title": "string",
          "items": {
            "additionalProp1": "string",
            "additionalProp2": "string",
            "additionalProp3": "string"
          }
        }
      ]
    }
  ],
  "page": {
    "page": 0,
    "pageSize": 0,
    "total": 0
  },
  "posStatus": "Accepted"
}

Schema CouponCodeDisplayDtoPosApiListResponse
Represents the response containing a list of coupon codes available to the POS system.

data (array of CouponCodeDisplayDto, nullable) – List of coupon codes
page (PageModel) – Pagination metadata
posStatus (enum: Accepted, Disabled, NotAvailable) – POS response status

CouponCodeDisplayDto
Represents coupon code display data.

rewardProvider (enum: TwoReward, PJM) – Reward provider type
code (string, nullable) – Coupon code
name (string, nullable) – Coupon name
title (string, nullable) – Coupon title
pictureUrl (string, nullable) – URL to the coupon image
availableUntil (string, date-time, nullable) – Expiration date of the coupon
status (enum: Issued, Redeemed, Cancelled, Expired) – Coupon status
info (array of CouponCodeDisplayInfoDto, nullable) – Additional coupon information

CouponCodeDisplayInfoDto
Represents an additional information section for a coupon.

title (string, nullable) – Section title
items (object, nullable) – Key-value data for the section

PageModel

page (integer) – Current page
pageSize (integer) – Number of items per page
total (integer) – Total number of items

2. Validate coupon

Endpoint:
POST /pos/{posSystemId}/coupon/validate/byTransaction Description:
Validates customer coupon by transaction Requires sessionId obtained from /startInteraction. Path Parameters:

posSystemId (string, required) – POS system identifier.

Example Request

{
  "sessionId": "string",
  "campaignId": "string",
  "transactionId": "string",
  "couponUser": {
    "firstName": "string",
    "lastName": "string",
    "gender": "string",
    "phone": "string",
    "email": "string"
  }
}

Responses

200 (Success)

{
  "posStatus": "Accepted",
  "data": {
    "externalSessionId": "string",
    "status": "string",
    "validationDate": "2025-09-25T08:08:35.448Z",
    "errorMessage": "string"
  }
}

Schema ValidateCouponSessionDtoPosApiResponse
Represents the response returned when validating a coupon session.

posStatus (enum: Accepted, Disabled, NotAvailable) – POS response status
data (ValidateCouponSessionDto) – Coupon session validation result

ValidateCouponSessionDto
Represents the result of a coupon session validation.

externalSessionId (string, nullable) – External coupon session identifier
status (string, nullable) – Validation status of the coupon
validationDate (string, date-time, nullable) – Date and time of validation
errorMessage (string, nullable) – Error message if validation fails

Getting Started

Integration Options

API

Loyalty Program

1. Transaction

1. Get POS Settings

Responses

Response parameters

2. Start POS Interaction

Example Request

Example Response (200 Success)

3. Submit Transaction

Example Request

Example Response (200 Success)

2. Customer Check-In & Loyalty Card retrieval

1. Get a Webhook with the Customer Details

2. Get Loyalty Card details

GET /v2/pos//loyaltyCard/lookup

Request

Responses

Schema

3. Coupon validation

1. Get customer coupons

Example Request

Responses

2. Validate coupon

Example Request

Responses

Getting Started

Integration Options

API

​1. Transaction

​1. Get POS Settings

​Responses

​Response parameters

​2. Start POS Interaction

​Example Request

​Example Response (200 Success)

​3. Submit Transaction

​Example Request

​Example Response (200 Success)

​2. Customer Check-In & Loyalty Card retrieval

​1. Get a Webhook with the Customer Details

​2. Get Loyalty Card details

​GET /v2/pos//loyaltyCard/lookup

​Request

​Responses

​Schema

​3. Coupon validation

​1. Get customer coupons

​Example Request

​Responses

​2. Validate coupon

​Example Request

​Responses

1. Transaction

1. Get POS Settings

Responses

Response parameters

2. Start POS Interaction

Example Request

Example Response (200 Success)

3. Submit Transaction

Example Request

Example Response (200 Success)

2. Customer Check-In & Loyalty Card retrieval

1. Get a Webhook with the Customer Details

2. Get Loyalty Card details

GET /v2/pos//loyaltyCard/lookup

Request

Responses

Schema

3. Coupon validation

1. Get customer coupons

Example Request

Responses

2. Validate coupon

Example Request

Responses
